2022 Norco Range C2 29"

Available in store: Check availability

Available in store

29" Wheels | 170mm Rear/170 Front | 63.5° Head Tube
Add to cart
Delivery time: 5-7 Business Days
Frame Carbon
Wheel Size 29"
Travel 170mm Rear/170 Front
Fork RockShox ZEB Ultimate RC2, 170mm Travel, 44mm Offset
Rear Shock FOX DHX2 Factory Coil, HSC/LSC, HSR/LSR, Custom Tune, 205x65mm Trunnion
Headset FSA #57E Internal Sealed Bearing
Bottom Bracket SRAM DUB PF92, Custom MRP SXg
Shifter SRAM GX Eagle
Rear Derailleur SRAM GX Eagle
Cassette SRAM Eagle XG 1275, 10-52T
Chain SRAM Eagle
Chainring 32T
Crankset SRAM GX Eagle, DUB, 170mm
Brakes SRAM Code R, 4 Piston, Metallic Pads
Rotors SRAM Centerline, 200/200mm
Seatpost TranzX YSP-105 Adjustable Dropper, 34.9mm, 150mm (S), 170mm (M). 200mm (L, XL)
Handlebar Deity Ridgeline, 800mm, 25mm Rise
Stem CNC Alloy, 40mm Length, 35mm Clamp
Grips DMR DeathGrip Soft, Thin (S, M), Thick (L,XL)
Saddle Ergon SM10 Enduro
Pedals N/A
Front Wheel e*thirteen LG1 EN, 32H, 29" (Hub: DT Swiss 350, 15x110mm Boost, 6 Bolt)
Rear Wheel e*thirteen LG1 EN, 32H, 29" (Hub: DT Swiss 350, 12x148mm Boost, XD, 36T engagement, 6 Bolt)
Front Tire Maxxis Assegai 2.5", DD, 3C MaxxGrip, TR
Rear Tire Maxxis Dissector 2.4", WT, DD, 3C MaxxGrip, TR
Sizes S, M, L, XL

Precision tracking in the rough, superior climbing efficiency and a completely new angle on suspension make the Range C2 the fastest bike in Enduro, and your ultimate Big Mountain companion.


High Virtual Pivot

The High Virtual Pivot design’s pivot point is not fixed and moves as the suspension cycles. This creates a rearward axle path while controlling its path through suspension travel to provide lower levels of anti-rise than would be possible with a HSP layout of similar axle path. This translates into a suspension that carries momentum exceptionally in rough terrain due to its axle path but remains active under braking to maintain grip and control.

The Range C2 will take your riding to next level. With 170mm of suspension travel front & rear and precision handling, the Range C2 makes the speed feel easy, helps maintain momentum on rough descents and makes the most of every pedal stroke.

What prompted the move away from the high single pivot design?

Norco re-defined how riders perceive high pivot bikes with the Aurum HSP. When we introduced it, it was a state-of-the-art, Factory Team-proven solution that confirmed how a rearward axle path helps maintain momentum in the rough while minimizing drivetrain kickback.

In the years since its introduction, technology has progressed. Our research and Factory Team development confirms that the Range’s High Virtual Pivot design allows a comparable rearward axle path to HSP while allowing the rear suspension to remain more active under braking than is possible with high single pivot designs.

Why does it need an idler?

Due to Range’s rearward axle path, the distance between the rear axle and BB grows considerably as the suspension moves through its travel. Routing the chain directly between the BB and cassette with this axle path would result in a dysfunctional level of anti-squat and significant chain growth causing excessive pedal kickback. Routing the chain around an idler in a location that minimizes chain growth better isolates the rider from inputs at the rear wheel, resulting in reduced rider fatigue. Additionally, the ability to control anti-squat with idler location provides a stable platform when pedaling.


    S M L XL
  Travel (mm front/mm rear) 170/170
  Reach 420 450 480 510
  Stack 618 630 641 653
HTA Head Tube Angle 63.75 63.5 63.25 63
OS Fork Offset 44
ST Seat Tube Length 370 395 410 455
STA Effective Seat Tube Angle 76.5 76.8 77.0 77.3
RC Rear Centre Length 440 440 442.5 447.5
BB Bottom Bracket Drop 20
BBH Bottom Bracket Height 355
HTT Horizontal Top Tube 568 598 628 658
WB Wheelbase 1203 1243 1285 1329
SOH Standover 662 663 665 695
HT Head Tube Length 100 115 130 145
  Trail 136 138 140 142
  Recommended Seatpost Drop 150 170 200 200
  Maximum Post Insertion 245 275 290 335
  Stem Length 40
  Crank Length 170
  Tire Size 2.35" – 2.5"
  Water Bottle Compatible 1 x 750 mL

Measured in mm
